Metal Enclosure Fanless Panel Pc VESA Embedded 15.6 Inch With Barcode Reader

  • 1
  • 2
  • 3

Brand Name : INNODAPC

Model Number : IND156PC

Certification : CE,RoHS, FCC

Place of Origin : Shenzhen,China

MOQ : 1piece

Price : Negotiable

Payment Terms : T/T, Western Union, L/C, Paypal/D/P, D/A, MoneyGram

Supply Ability : 5000 pieces per month

Delivery Time : 12working days upon receive the payment

Packaging Details : 1pc/carton weight: 4kgs/pc, packing size: 48×39×14cm

Type : 15.6inch Industrial Panel Pc

Size : INNODAPC 15.6inch LCD panel

Touchscreen : Capacitive touch screen

CPU : Intel J4105

System : Windows 7/10(trial version) / LInux / Ubuntu

Material : Aluminum Metal case

WIFI : Optional

I/O port : USB, COM, Rj45, VGA, HDMI

Contact Now

15.6inch 16:9 Aspect Metal Enclosure Fanless Industrial Panel Pc With Barcode Reader



Features

1. Intel J4105 processor

2. 10points capacitive touch screen

3. 9-36V wide voltage integrated

4. Various ports: 4*USB, 1*LAN, 1*COM, HDMI, VGA

5. Barcode reader built-in

6. Metal frame



Configuration

INNODAPC Processor System CPU Intel quad-core J4105
Memory 2GB (up to 8G)
Storage 32G SSD(up to 1TB)
Operation System WIndows 7/8/10 OS(trial version)
LCD Panel Characteristics Screen Size 15.6’’ LED Panel
Touchscreen Type Resistive touch screen / Capacitive touch screen
Resolution 1920(H)x 1080(V)
Aspect Ratio 16:9
Brightness 250cd/m2
Contrast Ratio 500:1
Response Time 10 msec
I/O Interface COM 1 x COM
USB 4xUSB2.0
LAN 1xRJ45, 10/100/1000 Mbps
VGA  Yes
Function(Optioanal) Front IP65
Barcode reader
9-36V wide voltage
Optional AG / AR glass
8-36V wide range voltage
Brightness control button
1000nits High Brightness for sunlight readable
Front waterproof / Full sealed Waterproof
Power Supply Single 12 V DC power input, Max 18W Power Consumption
Accessories 8A Power Adapter with cable
Working Temperature -20~70° C
Other Information Material Stainless steel+ Metal frame
Color Black/Silver/White
Mounting VESA mount / Embedded



Customization
size-7-42inch optional
Touch-capacitive/ Resistive/IR touch
AG / AR glass
Optically bound
1000cd/m2 sunlight readable brightness

waterproof ip65/67


Application
Intelligent Fab Automation
HMI system
Self-service pay station
Electrical fire monitoring system
water supply control cabinet
Parking payment machine
Intelligent Transportation
medical equipment
Electric control cabinet
Ticket Vending Machine



Our Advantage
1. Experience
INNODA have 10years rich experience in Industrial Computer/monitor filed. Our eingineers all have at least 13years experience.
2. Wide products line
7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android tablet...etc. which have excellent work performane.
3. Customization functions
It offers rich of interface to meet csutomers needs.
4.Widely useage environment
INNODA computer/monitor which is widly used for kitchen,food industry, boat...etc
